The skID (Model R1280IE, R1280IU) is a portable RAIN RFID reader of the easy2read© product line with integrated antenna for medium range applications. The reader hosts an internal rechargeable battery and can operate both in wired mode, using a USB cable, or in wireless mode through the Bluetooth® interface.

Thanks to the Bluetooth® communication interface, the skID is a perfect addon for any Bluetooth® enabled host such as a PC, a smartphone, a PDA or a tablet for RAIN RFID readings. The reader is compatible with Windows 8/10, Windows CE/Mobile, Android and iOS operating systems. The device supports both Bluetooth Low Energy (BLE) and Bluetooth classic communication to provide the maximum usage flexibility, including the HID profile for keyboard emulation.

• RAIN RFID (UHF EPC Class1 Gen2, ISO 18000-63) compliant
• ETSI and FCC versions available
• Bluetooth communication
• Integrated circular polarized antenna
• Ergonomic form factor
• Battery powered
• iPhone/iPad compatibility
• 4 mounting options: magnetic, 3M Dual Lock™, Quad Lock© or SP-Connect™

The skID can be easily fixed to the smartphone using 4 different methods: magnets, 3M Dual Lock, Quad Lock or SP-Connect Designed for mobile operators, the skID is ideal for inventory management, mobile workers, service and maintenance applications.

30 dBm 1-Port RAIN RFID Reader Module

The Lepton7 (Model R7100C), an embedded reader of the easy2read© product line, is an ultra compact reader for low power, high performance RAIN RFID applications.

With programmable output power from 10 dBm to 30 dBm, the reader can detect tags at more than 5 m of distance (depending on antenna and tag dimensions).

Due to its low power consumption, the module is specifically designed to be easily integrated in battery powered devices.

• RAIN RFID (UHF EPC Class1 Gen2, ISO 18000-63) compliant
• Multiregional support
• Ultra compact size
• Up to 30 dBm (1 W) output power
• Serial interface (TTL Levels)
• Low power consumption

The radio frequency core of the module is based on the Impinj E710 IC that permits to achieve fast reading speed and to be used in dense reader and dense tag environments for top-class rated performances.

The compactness of the device and the surface mount technology allow to embed the Lepton7 inside the new small form factor industrial handhelds, smartphone accessories and other compact form factor devices.

The Lepton7 complies with and can operate in both European and US regulatory environments and, thanks to its multiregional capability, it’s ideal for integration in devices requiring compliance to different geographical regions.

The Lepton7 is pin-to-pin compatible with the Impinj RS1000 and RS500 and with the CAEN RFID Hadronmini module making it a perfect replacement for these devices.

Industrial 4-port RAIN RFID Long Range Reader

The Proton (Model R4320P) is a rugged long range RAIN RFID reader of the easy2read© product line, well suited for industrial environment installations.

The Proton reader has 4 antenna ports capable of a 31.5 dBm maximum power enabling to build RAIN RFID portals for logistics. Its compact form factor makes it easy to install and the IP65 protection permits outdoor or harsh environment installations. Featuring Power Over Ethernet, RS232 and GPIOs via industry standard M12 connectors the Proton is an ideal choice for industrial automation and Industry 4.0 solutions.

• RAIN RFID (UHF EPC Class1 Gen2, ISO 18000-63) compliant
• Multiregional support
• Four 50 Ohm TNC-RP antenna connectors
• Power over Ethernet interface
• Up to 31.5 dBm (1.4 W) output power
• Internal scripting engine
• IP65 in compact form factor
• PoE or external power supply
• M12 industrial connectors
• Development Kit available

The Proton is based upon an embedded Linux platform and it’s easily configurable using an internal web interface. System integrators can customize the behavior of the reader installing Java code that, having access to all the RFID features and interfaces, permits a full customization.

The Proton reader complies with and can operate in both European and US regulatory environments and, due to its multiregional capabilities, it’s ideal for integration in devices requiring compliance to different geographical regions.

30dBm 4-Port RAIN RFID Reader Module

The Lepton9x4 (Model R9104C), an embedded reader of the easy2read© product line, is an ultra compact reader for low power, high performance RAIN RFID applications. With programmable output power from 10 dBm to 30 dBm, the reader can detect tags at more than 5 m of distance (depending on antenna and tag dimensions). Due to its low power consumption, the module is specifically designed to be easily integrated in battery powered devices.

The radio frequency core of the module is based on the Impinj E910 IC that permits to achieve fast reading speed and to be used in dense reader and dense tag environments for top-class rated performances. The compactness of the device allow to embed the Lepton9x4 inside industrial handhelds, smartphone accessories and other compact form factor devices.

The Lepton⁹x4 complies with and can operate in both European and US regulatory environments and, thanks to its multiregional capabilities, it’s ideal for integration in devices requiring compliance to different geographical regions.

The Lepton⁹x4 is designed on the basis of the Lepton⁹ with the aim to facilitate the integration for those who prefer to use connectors instead of automatic manufacturing required by the SMD form factor. The Lepton9x4 has also a wider power supply voltage range to permit to connect it directly to battery packs.

• RAIN RFID (UHF EPC Class1 Gen2, ISO 18000-63) compliant
• Multiregional support
• Ultra compact size
• Up to 30 dBm (1 W) output power
• 4 antenna ports
• Serial interface (TTL Levels)
• Low power consumption

Applications:

• Handheld devices
• Multiregional label printers and applicators
• Points of sale readers
• Voice operated gloves

The trID (Model R1210I) is a slim RAIN RFID reader of the easy2read© product line with integrated antenna for short range applications.

The reader hosts an internal rechargeable battery and can operate both in wired mode, using a USB cable, or in wireless mode through the Bluetooth® interface. Thanks to the Bluetooth® communication interface, the trID can be connected to any Bluetooth® enabled host such as a PC, a smartphone, a PDA or a tablet for RAIN RFID readings.

• RAIN RFID (UHF EPC Class1 Gen2, ISO 18000-63) compliant
• ETSI and FCC versions available
• Bluetooth communication
• Integrated near field antenna
• Slim form factor
• Battery powered
• iPhone/iPad compatibility

The reader is compatible with Windows 8/10, Windows CE/Mobile, Android and iOS operating systems. The device supports both Bluetooth Low Energy (BLE) and Bluetooth classic communication to provide the maximum usage flexibility, including the HID profile for keyboard emulation.

The trID slim form factor permits to embed the reader in jewelry trays or to use it on a desk for document tracking or in healthcare environment to track surgery or dental tools.

fIDo (Model R1307IE, R1307IU) is a RAIN RFID sled reader of the easy2read© product line with integrated antenna for long range applications. The reader hosts an internal rechargeable battery and can operate both in wired mode, using a USB cable, or in wireless mode through the BLE/Bluetooth® interface.

Thanks to the Bluetooth® communication interface, the fIDo is a perfect add-on for any Bluetooth® enabled host such as a PC, a smartphone, a PDA or a tablet for RAIN RFID readings. The reader is compatible with Windows 8/10, Windows CE/Mobile, Android and iOS operating systems. The device supports both Bluetooth Low Energy (BLE) and Bluetooth classic communication to provide the maximum usage flexibility, including the HID profile for keyboard emulation.

• RAIN RFID (UHF EPC Class1 Gen2, ISO 18000-63) compliant
• ETSI and FCC versions available
• Bluetooth/BLE communication
• Integrated circular polarized antenna
• Ergonomic form factor
• Battery powered
• iPhone/iPad compatibility
• SP-Connect™ universal mounting for smartphones
• Embedded smartphone wireless charger
• Optional barcode scanner

fIDo integrate a SP-Connect SPC+ mounting adapter to easily fix a wide range of smartphones with dedicated phone cases. It also embeds a wireless charging transmitter to charge the smartphone without the need to detach it from the reader.

fIDo is ideal for inventory management, mobile workers, service and maintenance applications, asset tracking and many other AutoID applications. The radio frequency core of the reader is based on the Impinj E710 IC that permits to achieve fast reading speed and to be used in dense reader and dense tag environments for top-class rated performances.
