A4030C Circularly Polarised Antenna

Compact UHF RFID Antenna for Reliable Read Performance

The Times-7 A4030C is a compact circularly polarized UHF RFID antenna designed for reliable performance across a wide range of RFID applications. Part of the SlimLine™ antenna family, it combines a low-profile form factor with strong read capability, making it well suited for retail, logistics, inventory management, and point-of-sale environments.

With a typical read range of up to 6 meters, the A4030C supports accurate item identification and tracking across shelves, stockrooms, packing stations, and self-service retail areas. Its circular polarization helps maintain dependable tag reads in dynamic real-world environments where tag orientation can vary.

The antenna measures just 280 x 280 x 12.2 mm, allowing it to fit into space-constrained installations while maintaining a clean and discreet appearance. A rear SMA connector further supports seamless integration by keeping cabling hidden from view.

Built for dependable indoor and outdoor use, the A4030C features an IP65-rated housing made from fire-retardant ABS and operates in temperatures from -20 °C to +55 °C. With support for both ETSI (865–868 MHz) and FCC (902–928 MHz) frequency ranges, it can be deployed across global RFID projects.

Its typical 6.5 dBiC gain, 60° beamwidth, and robust design make the A4030C a strong choice for businesses seeking a versatile fixed RFID antenna that balances performance, aesthetics, and installation flexibility.

Key Features

• Circularly polarized antenna with RHCP (Right Hand Circular Polarisation)

• Compact dimensions for easy integration: 280mm x 280mm x 12.2mm

• Rear SMA female connector for clean and discreet installation

• Robust fire retardant ABS radome with IP65 rating for outdoor durability

• Typical read range: 6 meters

• Designed for inventory management, logistics and supply chain, retail, and POS self-service applications

Applications

• Inventory Management: Rugged design ideal for asset tracking and encoding RFID tags; suitable for manufacturers, wholesalers, and retailers throughout the supply chain.

• Logistics & Supply Chain: Enables accurate counting, correction, and tracking of individual items and cartons from factory tagging to distribution and retail.

• Retail / POS Self Service: Compact and aesthetically pleasing design fits well within space-constrained retail environments.

Installation & Mounting

• Supports 100 x 100 mm VESA spaced mounting brackets

• Slim design allows totally flush mounting using corner mounting holes

• Caution to use finger tightness only when connecting SMA; avoid tool tightening to prevent damage.

Ordering Information

• Available in ETSI (865-868 MHz) and FCC (902-928 MHz) frequency bands

• Mounting accessories and various cable lengths/options available

Times-7 backs its antennas with strong customer service and technical support to ensure successful implementations worldwide.
