Monochrome Drop-On-Demand (DOD) Print Module

Drop-on-Demand Monochrome Printing for Encoded Cards & Tickets

The Rinas thermal drop-on-demand (DOD) variable data monochrome printing system is a powerful print module designed to complement MagStripe, RFID and smart card encoding solutions. Based on state-of-the-art piezoelectric technology, it enables high-resolution, on-demand printing of variable data on plastic cards and paper tickets.

The transport speed of the card or ticket under the print head can be flexibly adjusted to suit the operational environment – this also defines the UV exposure time for curing. As an ideal extension to the modular Rinas CS-LWR and CS-SWR universal encoders, the DOD printer integrates seamlessly into customized encoding and printing configurations.

Intelligent (µC-controlled) modules allow tailored system setups that precisely match customer requirements in terms of throughput, data handling and process reliability.

Key Facts

• Borderless ID-1 printing for full-face card layouts

• Print width: 54 mm

• Printing on various materials (e.g. paper, PVC, ABS, bio-based materials)

• Head temperature control for stable, high-quality output

• Durable construction for continuous and industrial operation

• Integrated LED UV curing system for instant ink curing

• Support for 1D and 2D barcodes

• Built-in fonts and support for all Windows TrueType (TTF) fonts

• High-quality graphical output

• Print resolution:

  • Typical: 600 × 600 dpi

  • Maximum: 600 × 1,200 dpi

Applications

• Encoding and printing of cards and tickets for:

  • Public transport

  • Access control

  • Club and membership programs

  • Gift cards

  • Ski passes and leisure applications

• Printing on different substrates such as paper, PVC, ABS and bio materials

• Flexible encoding workflows:

  • Encoding performed directly by the customer with data synchronization to Rinas software

  • Or encoding as a service provided by Rinas when specifications are clearly defined

• Ideal for systems where variable data, barcodes and personalization must be printed in-line with MagStripe, RFID or chip encoding.
