TELID®310.pro: Temperature Data Logger with RFID Interface

RFID Temperature Data Logger for Precise Contactless Monitoring

The TELID®310.pro RFID temperature data logger is designed for accurate, contactless temperature monitoring in industrial, medical, pharmaceutical, and food processing environments. Built for reliability and long-term use, this wireless sensor enables seamless data collection without physical connections.

With a measurement range of -30 °C to +140 °C and high accuracy, the TELID®310.pro is ideal for temperature validation, process monitoring, and quality assurance. The integrated RFID interface based on ISO15693 / NFC-V allows fast and secure data transfer using compatible readers or mobile devices, making it a powerful solution for modern IoT applications.

The compact and robust design with IP67 protection ensures performance in harsh environments, including humid conditions and applications where the device may be exposed to water. It can be mounted on both metal and non-metal surfaces, offering flexibility across a wide range of use cases.

The device features a large internal memory for continuous temperature logging, with configurable sampling intervals from seconds to hours. Users can define start and stop times, logging modes, and measurement settings to match specific process requirements. This makes the sensor particularly suitable for cold chain monitoring, sterilization processes, and industrial validation tasks.

A built-in long-life battery supports extended operation, reducing maintenance and enabling reliable long-term deployments. Advanced security features such as password protection and authentication ensure safe handling of sensitive data.

The TELID®310.pro RFID temperature sensor is a smart solution for companies looking to improve process transparency, ensure compliance, and implement efficient wireless monitoring systems in the Internet of Things.

Key Features

• Contactless RFID interface operating at 13.56 MHz with up to 15 mm communication distance

• High-accuracy temperature sensor with typical ±0.05 °C accuracy and 0.0625 °C resolution

• Quartz and MEMS stabilized real-time clock for precise timing

• Non-volatile memory capable of storing 32,250 temperature samples

• Robust, sealed PPSU housing with stainless steel reinforcement (IP67 rated)

• Energy-efficient Li primary cell battery with up to 5 years lifetime

• Supports data logging modes including compressed and limit-based logging, programmable start/stop times

• Driverless operation using text/plain NDEF messages and compatibility with various iID® reader devices

• Its secure features include password protection, AES authentication, and ECC-based originality signature to ensure data integrity.

Additional Models

• TELID®311.pro-D30MP: Battery-powered logger for temperatures up to +125°C with blue housing

• TELID®311.ac.pro-D30MP: Designed for industrial sterilization and autoclaving up to +140°C with red housing

For industrial, desktop/OEM, and mobile environments, compatible readers include iID®M18/M30, TELID®station, iID®POCKETwork, and others.
