UHF RFID WideRange 25° 35° PRO Antenna

Wide Range 25°35° PRO Antenna Unit

Manufacturer: KATHREIN Solutions

The Wide Range 25°35° PRO is a high-gain, linearly polarized passive UHF RFID antenna optimized for selective lane detection of vehicles (e.g., windshield labels and headlamp tags).

With a focused 25° horizontal aperture it enables lane-selective reading in high-speed Multi Lane Free Flow (MLFF) and ITS applications. The rugged compact design and IP67 rating make it suitable for outdoor deployments.

Key Features

• 25° focused read zone for lane-selective vehicle detection (25° / 35° half-power beam width)

• High antenna gain and linear polarization for optimal reception of weaker transponders

• Read range: up to 30 m (depending on tag properties, environment and requirements)

• Rugged, compact design with thermoplastic UV-resistant radome and aluminium chassis

• Outdoor-ready: IP67 protection

Typical Applications

• Tolling systems

• Road access control

• Multi Lane Free Flow (MLFF)

• Smart city ITS deployments

Accessories

• Antenna cable R-AC-15-N-TNCR; 15 m low loss 400 antenna cable (Order no. 52010250)

Ordering / Versions

• ETSI version (865–868 MHz): Order no. 52010489

• FCC version (902–928 MHz): Order no. 52010490
