HF | NFC Embedded Module – M980

The iDTRONIC HF | NFC Embedded Module M980 is a high performance and low-cost Module for the integration into check-in counters, libraries, retail or shelving systems. With its cutting edge microcontroller and latest HF transceiver technology, the Module allows users to read and write 13.56 MHz transponders supporting the common RFID standard ISO15693.

Thanks to its 8 antenna ports the HF | NFC Embedded Module M980 achieves reading ranges of up to 10 cm (depending on type of transponder). Its serial-based interface RS485 allows an easy and fast integration into existing electronics or a fast paced new development of high-end identification applications.

iDTRONIC’s hardware comes with a useful SDK for the development of controller, Linux or Windows-based applications. Beside the documentation, command protocols and source codes, the SDK includes a Windows-based demo application with full functionality over the supported HF RFID standard.

Key Facts

• Frequency: 13,56 MHz

• 8 Antenna Ports

• RS485 Interface

• Reading Range: Up to 10 cm

• ISO15693

Application Fields:

• Library

• Retail

• Luggage Identification

• Shelving Systems

• Lean Production
