Integrated SMT Module for UHF RFID Performance
In an era where smart devices are becoming more compact and intelligent, space-saving technology must still deliver top-tier performance. With the M500, iDTRONIC introduces an Embedded SMT RFID Reading Module that brings full UHF RFID functionality to space-constrained applications – without compromising on power, precision, or flexibility.
At just 21 × 21 mm and weighing only 2.8 grams, the M500 is one of the smallest RFID modules in its class. Designed to be surface-mounted directly onto the PCB of your device, it integrates seamlessly into mobile platforms, industrial electronics, and compact RFID readers.
The module is built on SMT (Surface-Mount Technology), enabling highly automated production and efficient integration into modern electronic systems.
Performance Meets Compact Design
Despite its ultra-small footprint, the M500 delivers impressive capabilities. With up to 27 dBm configurable RF output power and the ability to read up to 1,000 tags per second, it’s a robust performer in demanding environments.
The module is available in three variants, based on Impinj’s E310, E510, or E710 ICs – allowing developers to select the right balance of speed, sensitivity, and power consumption.
Integration is made simple with standard interfaces like UART (3.3V TTL) and 2GPI/2GPO lines, supporting smooth communication with host systems. Real-time temperature monitoring ensures reliable performance, even under challenging operating conditions.
Developer-Friendly and Ready to Integrate
To support rapid development, iDTRONIC offers an optional carrier board for evaluation and a unified SDK compatible with Windows, Linux, and Android. This makes prototyping and integration across platforms quick and developer-friendly – an essential feature for OEMs working with tight schedules or lean teams.
Application Areas of the M500 Embedded SMT Module
The M500 is built for versatility and can be used in a wide range of industries and environments:
Industrial Automation: Enables high-speed identification of components during production, supporting traceability, quality control, and process automation.
Medical Technology: Tracks instruments, surgical kits, and disposable items reliably and securely – even in compact, sterilized devices.
Logistics & Conveyor Systems: Provides fast, accurate detection of tagged goods directly on conveyor belts – ideal for sorting, packaging, and inventory systems.
Mobile and Portable Devices: Its minimal size and weight make it perfect for integration into handheld terminals, wearables, and smartphones used in field operations or retail environments.
Built for Customization and Scalability
The Impinj IC options (E310, E510, E710) give integrators the flexibility to tailor performance to their use case:
E310 for energy-efficient applications
E510 for balanced read/write speed and sensitivity
E710 for high-speed, high-density tag reading environments
This modular approach means no hardware redesign is required if performance needs evolve – the right variant simply plugs into your development path.
German Engineering, Global Expertise
As a trusted RFID technology provider, iDTRONIC combines engineering precision with global market insight. The M500 Embedded SMT RFID Module is the latest example of their dedication to delivering compact, high-performance solutions that adapt to the realities of embedded electronics and modern product design.
For full specifications and evaluation options: M500 Product Page – iDTRONIC RFID
Conclusion:
With the M500, iDTRONIC sets a new benchmark for embedded RFID modules. It brings full UHF RFID performance, flexible interfaces, and developer-ready tools into a compact SMT form – ideal for next-generation smart devices and embedded systems.Whether you're building solutions for industry, healthcare, or mobile operations, the M500 is the RFID engine to power your innovation.
