iID wearable UHF: Wearable UHF-RFID & wrist scanner

Hands-Free UHF RFID Scanning for Mobile Data Capture

The iID®wearable UHF is a compact, wrist-mounted RFID reader developed by microsensys, designed for efficient, hands-free data capture in industrial, logistics, and administrative environments. Combining mobility with performance, this wearable scanner enables users to identify, track, and manage assets in real time without interrupting their workflow.

Equipped with a UHF RFID interface based on ISO 18000-6C, the device supports a wide range of transponders, including common chip families from NXP, Impinj, and Alien. With a read range of up to 150 cm, it allows fast and reliable scanning of multiple items, making it ideal for applications such as inventory management, material handling, and asset tracking.

The ergonomic design ensures comfortable use throughout the day. Worn on the wrist or attached via a badge holder, the reader enables true hands-free operation. Scanning can be triggered via a button, motion sensor, or directly through a connected host device, providing flexibility for different workflows.

Data is transmitted wirelessly via Bluetooth Low Energy (BLE) to mobile devices or backend systems, ensuring seamless integration into existing infrastructures. Visual, acoustic, and haptic feedback through LEDs, buzzer, and vibration signals provide clear user interaction and status indication in any environment.

Powered by a rechargeable Li-Ion battery, the device offers up to 10 hours of operation, supporting full working shifts. Its robust construction, combined with a lightweight form factor of approximately 40 grams, ensures durability without compromising comfort.

The iID®wearable UHF is an ideal solution for companies seeking to enhance efficiency, reduce manual effort, and enable real-time visibility in their RFID-based processes.

Key Features

• Lightweight and smart design

• Alerts via vibration, buzzer, and LED indicators

• Scan trigger options: motion, button, or host controlled

• Hands-free use by wearing on the wrist or with a badge holder accessory

• Seamless data transfer through Bluetooth™ Low Energy

• Supports a broad range of UHF transponder chips including optional sensor functionality

Technical Highlights

• RFID air interface based on ISO 18000-6c standard

• Compatible chip solutions: NXP U-Code, Alien Higgs, Impinj Monza, TELID®400, TELID®500

• Operating communication range up to 150 cm depending on transponder and environment

• Bluetooth™ Low Energy GATT wireless host interface for up to 10m range

• Rechargeable Li-Ion battery with typical operation time of 10 hours

• Compact and lightweight: 47 x 60 x 13 mm, approximately 40g

• Protection class IP54 meets EU emission standards (EN 302 208)

Applications

Ideal for smart mobile wireless data capture requirements in logistics, industrial settings, and administrative environments where hands-free, reliable, and flexible RFID reading/writing capabilities are critical.
