UHF mid range reader ID MRU400iX

Industrial UHF Mid-Range Reader with Integrated Antenna

The ID MRU400X from FEIG is a robust industrial UHF mid-range RFID reader designed for demanding applications in industry, logistics, and railway environments.

Featuring an integrated circularly polarized antenna and up to 1 Watt output power, the reader enables reliable identification of EPC Class1 Gen2 and ISO 18000-63 transponders at read ranges of more than 4 meters.

Built for harsh indoor and outdoor environments (IP65/IP67), the MRU400X comes in a rugged aluminum housing with industrial-grade M12 connectors. This makes it ideal for installation on machines, conveyor systems, forklifts, and rail vehicles. The reader is designed to meet railway standards such as EN 50155 and supports applications including position detection, passenger information updates, and selective door control.

Beyond RFID performance, the MRU400X serves as an edge computing platform. Equipped with a Linux-based system (ARM Cortex-A7 + Cortex-M4), it enables custom applications to run directly on the device. Secure key storage via a secure element and support for authentication mechanisms according to ISO/IEC 29167 allow the implementation of secure UHF RFID systems.

Key Features

• Integrated antenna for "all-in-one" reading requiring no external antenna

• 1 Watt ERP output power with adjustable external antenna power in 100 mW steps

• Supports transponders compliant with EPC Class1 Gen2 and ISO 18000-63 standards

• Secure UHF system support via EPC Class1 Gen2 and ISO 29167, including NXP UCODE DNA

• Secure Element for protected storage of application keys

• Interfaces include RS485, Ethernet (IPv4/IPv6), USB (On-the-Go)

• 1 Input, 1 Optocoupler Output and 1 Relay Output for controlling external components and signaling

• Edge computing platform with ARM Cortex-A7 and Cortex-M4 processors

• Rugged design suited for industrial, railway, logistics, machine, forklift, and conveyor system applications

• Multiple mounting options: flat surface, post (VESA), DIN rail adapter, or chassis with plastic insulation

• Protection against antenna faults, mismatching, and electrostatic discharge

Applications

• Railway: reading vehicle position markings, passenger info updates, selective door opening

• Industrial and logistics: rugged environments on machines and mobile equipment

Certifications and Standards

• Radio standards and licensing for Europe, UK, USA, Canada

• EMC, safety, cyber security standards compliance

• Railway environment specific certifications including vibration, fire protection, wet heat, salt mist resistance
