Lepton9x4 - R9104C Reader Module

30dBm 4-Port RAIN RFID Reader Module

The Lepton⁹x4 (Model R9104C), an embedded reader of the easy2read© product line, is an ultra-compact reader for low-power, high-performance RAIN RFID applications, making it the perfect solution for your needs! With a programmable output power from 10 dBm to 30 dBm, the reader can detect tags at a distance of more than 5 m (depending on antenna and tag dimensions).

Due to its low power consumption, the module is specifically designed for easy integration into battery powered devices.

The module’s RF core is based on Impinj’s E910 IC, which enables fast reading speeds and high performance in dense reader and tag environments. The device’s compact size allows the Lepton⁹x4 to be embedded in industrial handhelds, smartphone accessories and other compact form factor devices.

The Lepton⁹x4 is compliant and can operate in both European and U.S. regulatory environments, and its multi-regional capabilities make it ideal for integration into devices that must comply with different geographic regions.

The Lepton⁹x4 builds upon the foundation of the Lepton⁹, offering a more integration-friendly design for those who prefer connectors over the automated assembly process associated with SMD* components. Additionally, it features a wider power supply voltage range, enabling direct connection to battery packs.

* SMD: Surface-Mount Device

Key Facts

• RAIN RFID (UHF EPC Class1 Gen2, ISO 18000-63) compliant

• Multiregional support

• Ultra compact size

• Up to 30 dBm (1 W) output power

• 4 antenna ports

• Serial interface (TTL Levels)

• Low power consumption

Applications

• Handheld devices

• Multiregional label printers and applicators

• Points of sale readers

• Voice operated gloves
