IDENTControl Compact B40 RFID Evaluation Unit

The IDENTControl Compact B40 RFID evaluation unit from Pepperl+Fuchs is a versatile RFID identification system with an integrated Ethernet interface that supports the PROFINET and EtherNet/IP protocols.

The device is optimized for flexible use with read/write heads in the LF, HF, and UHF frequency ranges and offers high immunity to interference thanks to a comprehensive EMC design that includes a metal housing and grounding.

Key Features

• LED status indicator for bus communication with read/write heads

• Integrated 2-port switch enables Ethernet loop-through

• Connection of up to 2 read/write heads or, alternatively, 1 read/write head and 1 trigger sensor

• Compatible with numerous fieldbus systems such as PROFIBUS, PROFINET, Ethernet, EtherCAT, CC-Link, and serial interfaces (RS232, RS485)

• Suitable for control cabinet use and harsh field applications (IP67 protection rating)

• Plug-in connectors for easy installation and quick device replacement

Detailed Description

The IDENTControl Compact System from Pepperl+Fuchs enables simple and flexible system integration to reliably implement RFID applications in industrial environments. The numerous connection options and interfaces, as well as the use of trigger sensors, make the system particularly reliable and adaptable to a wide variety of applications.

Technical Highlights

• Robust aluminum housing, powder-coated

• Operating and storage temperature ranges: -25 to 70 °C and -40 to 85 °C

• Mechanical shock and impact resistance for harsh operating conditions

• Use of M12 connectors for read/write heads, power supply, and Ethernet

• Various network protocols (HTTP REST API, EtherNet/IP, PROFINET IO, SNMP, etc.)

Advantages

• High flexibility in system integration

• Robust design for industrial applications

• Clear LED indicators for status monitoring

• EMC-compliant and reliable for applications in the field as well as in control cabinets
