ARU 2400 UHF RFID Antenna Reader

Integrated RAIN RFID Reader for Industrial and IoT Applications

The ARU 2400 is a compact and powerful UHF RFID antenna reader designed for seamless integration into industrial environments. As part of the RAIN RFID ecosystem, it combines a high-performance reader module with an integrated wide-range antenna, delivering reliable identification and tracking capabilities for logistics, manufacturing, and supply chain applications.

All-in-One Reader with Integrated Antenna

The ARU 2400 stands out with its fully integrated 60° wide-range antenna, eliminating the need for complex external antenna setups. This simplifies installation and reduces system complexity, making it ideal for indoor deployments where space, efficiency, and ease of use are critical.

With up to +30 dBm transmit power and high receiver sensitivity, the device ensures stable and accurate tag detection across a wide range of use cases.

Built for Industry 4.0 and IoT Integration

Equipped with an embedded computing module and based on EPC Gen2v2 / ISO 18000-63 standards, the ARU 2400 supports all major UHF transponder chip features. This ensures compatibility with modern RFID infrastructures and enables integration into Industry 4.0 and IoT systems.

The reader includes Ethernet connectivity with Power over Ethernet (PoE), allowing both data transmission and power supply through a single cable. This reduces installation effort and supports flexible deployment in existing network environments.

Flexible Connectivity and System Integration

The ARU 2400 offers multiple connectivity options, including:

• Ethernet interface (10/100 Mbit/s)

• PoE support for simplified installation

• GPIO interfaces with 2 inputs and 2 outputs for process integration

• Additional antenna ports for extended coverage

These features make it easy to integrate the reader into automated workflows, control systems, and industrial processes.

Designed for Reliable Indoor Operation

The device is optimized for indoor use with an IP40 protection class and operates in temperatures from -20°C to +55°C. Its robust housing and industrial-grade components ensure stable performance in demanding environments such as production lines, warehouses, and healthcare facilities.

With compact dimensions of 300 × 300 × 49 mm, the ARU 2400 can be easily mounted on shelves, walls, or infrastructure elements.

Versatile Applications Across Industries

The ARU 2400 is suitable for a wide range of applications, including:

• Logistics and supply chain tracking

• Manufacturing and automotive processes

• Track and trace systems

• eKanban solutions

• Healthcare asset management

Its combination of integrated hardware, strong performance, and flexible interfaces makes it a reliable foundation for scalable RFID solutions.

Efficient Identification Made Simple

By combining reader, antenna, and processing unit in one device, the ARU 2400 reduces system complexity while delivering high-performance RFID capabilities. It enables companies to implement efficient identification and tracking systems that support transparency, automation, and digital transformation.
